Mil—spec cable harness capability





A. Material and Parts

Professional on M26482 , MIL-C-5015 , M24308 , D38999 serial connector RF MIL-C-39012 serial .Customize special connector.

MIL. Wire professional on M22759 , M27500 serial , coaxial RF M17/119-RG174.

Heat shrink tubing professional on M23053 and NTFR serial. Shielding Braid profession on RAY-101 serial.

Thin wall Heat shrinkable sleeve profession on TMS-SCE serial.

Circula MIL spec. Strain Reliefs professional on TXR54 and TXR40 serial. We have completed supply chain and source.



B. Manufacture Profess

The Crimping tool,insertion , Solder Iron , fixture, fixture board is ready and sufficent.We can design special tool for assembly and testing.

Testing Continuity , Isolation and Dielectric equiptment has TAF certification.

Logistic support use PC WIN10 and Execl.

Current capabibility Wire Harness production Length is 10 meters Max.

Diameter 30mm. Extandible to 15 meters and 50mm diameter.
